5700DL Ride-on Scraper



SKU: 5700DL: Scraper, Ride-On, 110 Volt, Dual Lift

Product Description

Twelve AGM 180-amp hour batteries, compact design, hydraulic steering, and a Dual-lift front end make this scraper a powerhouse.  The dual-lift feature on the front of the machine, enables the operator to make infinite adjustments to the blade angle and pitch without leaving the seat.

  • To increase the versatility of your machine, try National’s 1-inch Blades.
    • These are designed specifically for VCT removal and adhesive removal.
    • 1-inch blades do need to be used in a Razor Blade Cutting Head.  Pair the length of the blade you choose to the length of the cutting head when possible
  • An additional feature that can be added to our classic Rider are a set of lifting arms.  These steel arms are built into the frame and offer 3 points of contact for moving the machine via chains.
Power Supply Battery
Width* 24.5″ 62 cm
Height 50″ 127 cm
Length* 63″ 160 cm
Weight 2,407 lb 1,091 kg
Removable Weight 185 lb front 84 kg
Weight (machine only) 2,222 lb 1,007 kg
Speed up to 120 ft/min up to 36.6 m/min
Voltage 115 230
Frequency 60 Hz 50 Hz
* Measurements are without tooling attached
Meets the requirements of the Machine Directive 2006/42/EC and EMC Directive 2004/108/EC. It is CE marked.

Included with the 5700DL:

  • 5110-100: Transport Wheels
  • 402929: 3/4 x 1-1/8 Wrench
  • 73507-1: 7 ft extension cord
  • Kit 5175 includes:
    • 6277-BU: 45 degree, 3″ x 12″ self-scoring, bevel up
    • 6284: 3″ x 12″ heavy-duty blade
    • 7050-12: 12″ cutting head
    • 7079-2: 2″ x 6″ angle shank w/ carbide tip
  • One-year manufacturer’s warranty on parts and labor
